Levenhuk MED 60x Infinity Plan Achromatic Objective

Infinity-corrected. Spring-loaded frame. Magnification: 40x. Aperture: 0.8

Availability

Product ID	76078
Brand	Levenhuk, Inc., USA
Warranty	2
EAN	5905555004792
Package size (LxWxH)	3x6x3
Shipping Weight	0.106

Description

The Levenhuk MED 60x infinity plan achromatic objective is an accessory for laboratory infinity-corrected microscopes. It provides 60x magnification, flattens the field of view, eliminates optical aberrations, and allows for observing the microcosm in maximum detail. The objective renders high contrast and sharp images. The Levenhuk MED 60x infinity plan achromatic objective is an instrument for any professional microbiologist.

The objective's lenses are made of glass and housed in the metal body. The front lens features additional protection and a spring-loaded frame.

The kit includes:

Objective
Plastic case

Specifications
Lens material	optical glass
Body material	copper
Optical design	plan achromatic
Magnification, x	60
Aperture	0.85
Working distance, mm	0.5
Parfocal distance, mm	45
Cover glass thickness, mm	0.17
Compatible tube length, mm	infinity
Thread type	WJ 4/5"*1/36"
Spring-loaded frame	yes
Oil immersion	no

Specifications

Product ID	76078
Brand	Levenhuk, Inc., USA
Warranty	2
EAN	5905555004792
Package size (LxWxH)	3x6x3
Shipping Weight	0.106
