Levenhuk Plössl 40mm Eyepiece

see all

The price is valid only for the online store and may differ from the prices in retail stores.

Classic symmetrical eyepiece. Focal length: 40mm. Field of view: 48°

Plössl, 4 elements in 2 groups

Optical design is a set of optical elements that is assembled in a certain way

1.25

The barrel diameter of the accessory must match the barrel diameter of the device; otherwise, an adapter will be required

Fully multi-coated

The optics coating improves the image quality

Availability

Product ID	50764
Brand	Levenhuk, Inc., USA
Warranty	2 years
EAN	5905555003795
Package size (LxWxH)	11x5x5 cm
Shipping Weight	0.2 kg

Description

The Levenhuk Plössl 40mm long focus eyepiece is an excellent choice for observing deep sky objects. Due to its comfortable 48° field of view, it is well suited for studying extended nebulae, galaxies, and star clusters. It also features the filter thread.

The multi-element optical design consists of fully multi-coated glass lenses. They are housed in the robust aluminum body. The rubber eyecup has a fold-down design. The eyepiece long eye relief allows for observing when wearing glasses.

The eyepiece has a 1.25" barrel diameter, so that it is compatible with most modern telescopes

Features:

The long focus eyepiece is ideal for deep-sky observations.
48° field of view that is comfortable for searching for astronomical objects
Multi-element fully multi-coated glass optics
Long eye relief; fold-down rubber eyecup
1.25'' barrel diameter; filter thread

The kit includes:

Eyepiece
Protective caps – 2 pcs

Specifications

Product ID	50764
Brand	Levenhuk, Inc., USA
Warranty	2 years
EAN	5905555003795
Package size (LxWxH)	11x5x5 cm
Shipping Weight	0.2 kg
Type	standard
Optical scheme	Plössl, 4 elements in 2 groups
Barrel diameter, in	1.25
Optics material	optical glass
Lens coating	fully multi-coated
Focal length, mm	40
Field of view, °	48
Eye relief, mm	31
Suitable for observations while wearing glasses	✓
Eyepiece diameter, mm	1.25
Filter thread	✓
Filter thread	M28.5x0.6mm
Body	aluminum
Eyecup	rubber, foldable
Protective caps included	✓
Operating temperature range, °C	-5...+35

References
and downloads

High-resolution images (rar)

(ZIP, 9.71 Mb)

click to
download

Questions and Answers

Charles Malone (2016.06.04)

Hello, Levenhuk! Is this eyepiece suitable for konusmotor 70?

Customer service:

Levenhuk Plossl 40 mm Eyepiece is suitable for any telescope with 1.25'' eyepiece barrel diameter.

Jason Pena (2016.05.20)

Can I use this eyepiece for viewing nebulae and galaxies with levenhuk skymatic 105? Maybe some other options?

Customer service:

Levenhuk Plossl 40 mm Eyepiece is suitable for deep-sky viewing with Levenhuk SkyMatic 105 GT MAK.

Darrel Wiggins (2014.11.07)

Hello! Is this eyepiece suitable for Levenhuk Skyline 130x900 EQ?

Customer service:

Yes, Levenhuk Plossl 40 mm Eyepiece is suitable for Levenhuk Skyline 130x900 EQ. The magnification will be 22x.

Doyle Ware (2014.10.24)

Are you sure that field of view of this eyepiece is not 40 degrees?

Customer service:

The field of view of Levenhuk Plossl 40 mm Eyepiece is 50°.

Teres Dean (2014.08.01)

Is this eyepiece suitable for Levenhuk Strike 900 PRO?

Customer service:

Yes, the Levenhuk Plossl 40 mm eyepiece is suitable for the Levenhuk Strike 900 PRO telescope.

Thelma Spalding (2014.07.01)

Then how can I put it forward? Eye relief of 31 mm is specified as a fixed value and I didn't find any information on how to change position of the eyecup. I can't see it on images either.

Customer service:

You would not need to put the eyecup forward when using this eyepiece.

Thelma Spalding (2014.06.30)

Eye relief 31 mm - does it mean that an eye should be at 3 cm distance from the eyepiece? And eyecup is about 1 cm, so the eye is 2 cm away. Quoting the description: "Levenhuk Plossl is also fitted with a soft rubber eyecup that blocks most light rays coming from the sides during observations and provides for maximum comfort". Maybe this eyecup is telescopic? Or is it not suitable for those who don't wear glasses?

Customer service:

The Levenhuk Plossl 40 mm eyepiece has rubber eyecup but it's not telescopic. This eyepiece is suitable for people who wear glasses and those who don't.

Carl Bell (2014.04.05)

Is it ok for AstroMaster 70EQ?

Customer service:

Yes, Levenhuk Plossl 40 mm Eyepiece is suitable for use with your telescope.

JANE FINCH (2014.01.25)

Is it suitable for observing nebulae and comets?

Customer service:

Levenhuk Plossl 40 mm Eyepiece is perfect for observing deep-sky objects.

Submit your question/feedback
