MAGUS DF1 A 0.9 Darkfield Condenser

The price is valid only for the online store and may differ from the prices in retail stores.

For darkfield microscopy

Availability

Product ID	82922
Brand	MAGUS
Warranty	2 years
EAN	5905555019079
Package size (LxWxH)	5x8x5 cm
Shipping Weight	0.12 kg

Description

This condenser is for use in the darkfield microscopy technique. It is used to study unstained transparent samples with low light absorption that cannot be seen while using the brightfield techniques. It only works with dry (non-immersion) objectives with an aperture of up to 0.9, providing magnification in the range of 4x to 60x.

The MAGUS DF1 A 0.9 darkfield condenser is mounted on the microscope instead of the Abbe condenser for the brightfield microscopy. The optimal contrast of the image is achieved by using a cover glass of 0.17mm thickness and a glass slide of 1–1.2mm thickness.

Compatibility:

MAGUS Bio 230B Biological Microscope
MAGUS Bio 230BL Biological Microscope
MAGUS Bio 230T Biological Microscope
MAGUS Bio 230TL Biological Microscope
MAGUS Bio 250B Biological Microscope
MAGUS Bio 250BL Biological Microscope
MAGUS Bio 250T Biological Microscope
MAGUS Bio 250TL Biological Microscope
MAGUS Lum 400 Fluorescence Microscope
MAGUS Lum 400L Fluorescence Microscope

Specifications

Product ID	82922
Brand	MAGUS
Warranty	2 years
EAN	5905555019079
Package size (LxWxH)	5x8x5 cm
Shipping Weight	0.12 kg
N.A.	0.9
Immersion medium	none
Applicable objectives	4х, 10х, 20х, 40х, 60х
